MSI MAG PANO M100R PZ Micro ATX Tower Case, 1x USB 3.2, M-ATX/ ITX, 1x LED, 1x 2.5″, 1x 2.5″/3.5″, Micro ATX Tower

CASE FORM FACTOR Micro- ATX Tower
MOTHERBOARD FORM FACTOR SUPPORT M-ATX(Back-connect supported) / ITX

I/O PORTS
1 x USB 3.2 Gen 1 Type-A
1 x USB 3.2 Gen 2×2 Type-C
1 x Audio-Out / Mic-in
1 x LED Switch Button
1 x Power Button

DRIVE MOUNT SUPPORT 1 x 2.5″, 1 x 2.5″ / 3.5″ combo (up to 2 x 2.5” or 1 x 2.5”+ 1 x 3.5”)
EXPANSION SLOTS 5
MAXIMUM GPU LENGTH 390 mm / 15.35 inches
MAXIMUM CPU COOLER HEIGHT 175 mm / 6.9 inches
POWER SUPPLY SUPPORT ATX
MAXIMUM PSU LENGTH 200 mm / 7.87 inches (without 2.5″/3.5″ HDD tray installation)

FAN SIZE SUPPORT
Top: 3 x 120 mm / 2 x 140 mm
Front: NA
Rear: 1 x 120 mm / 1 x 140 mm
Side: 3 x 120 mm
Bottom: 1 x 120 mm
PSU Shroud: 2 x 120 mm

PRE-INSTALLED FAN SIZE Front: 3 x 120 mm, Rear: 1 x 120 mm
PRE-INSTALLED FAN TYPE Front: 3 x ARGB Fan, Rear: 1 x ARGB Fan

RADIATOR SIZE SUPPORT
Top: 120 / 240 / 360 mm
Front: NA
Rear: 120 / 140 mm
Side: NA
Bottom: NA

DIMENSIONS (DXWXH) 440 x 235 x 405 mm / 17.32 x 9.25 x 15.94 inches
NET WEIGHT 8.66 kg
GROSS WEIGHT 11.29 kg
